Description
PHILIPS BWS302 8LED 27K 24V S N10P20 911401753842
BWS302 8LED 27K 24V S N10P20
UniString is a surface mounted, exterior-rated and compact sized architectural LED
direct view string that is designed for architectural and media façade outdoor lighting
applications.;The robust mechanical design, easy installation and unique optical lenses
make UniString ideal for buildings/media facades, bridges, arenas, theaters, amusement
parks and recreational centers.;Available in white, monochromatic colors, RGB, RGBW and
tunable white.;Available in symmetrical and asymmetrical optical distributions with DMX control
option to give architects and designers the freedom to explore a wide range of concepts and
design with no limitations.
Product data
Overall length: 48 mm
Overall width: 15.5 mm
Overall height: 60.1 mm
Color: Black
Ingress protection code: IP66
Mech. impact protection code: IK06
Ambient temperature range: -40 to +50 °C
Initial LED luminaire efficacy: 71 lm/W
Net Weight (Piece): 0.070 kg
Remarks
PHILIPS BWS302 :
PHILIPS BWS302 8LED 27K 24V S N10P20 911401753842
PHILIPS BWS302 8LED 27K 24V S TM N10P20 911401753852
PHILIPS BWS302 8LED 27K 24V S DMX N10P20 911401753862
PHILIPS BWS302 8LED 27K 24V S DMX TM N10P20 911401753872
PHILIPS BWS302 8LED 30K 24V S N10P20 911401753882
PHILIPS BWS302 8LED 30K 24V S TM N10P20 911401753892
PHILIPS BWS302 8LED 30K 24V S DMX N10P20 911401753902
PHILIPS BWS302 8LED 30K 24V S DMX TM N10P20 911401753912
PHILIPS BWS302 8LED 40K 24V S N10P20 911401753922
PHILIPS BWS302 8LED 40K 24V S TM N10P20 911401753932
PHILIPS BWS302 8LED 40K 24V S DMX N10P20 911401753942
PHILIPS BWS302 8LED 40K 24V S DMX TM N10P20 911401753952
PHILIPS BWS302 9LED RGB 24V S DMX N10P20 911401753962
PHILIPS BWS302 9LED RGB 24V S DMX TM N10P20 911401753972
PHILIPS BWS302 9LED RGBNW 24V S DMX N10P20 911401753982
PHILIPS BWS302 9LED RGBNW 24V S DMX TM N10P20 911401753992
PHILIPS BWS302 8LED 27K 24V A LR N10P20 911401754002
PHILIPS BWS302 8LED 27K 24V A TM LR N10P20 911401754012
PHILIPS BWS302 8LED 27K 24V A DMX LR N10P20 911401754022
PHILIPS BWS302 8LED 27K 24V A DMX TM LR N10P20 911401754032
PHILIPS BWS302 8LED 27K 24V A TB N10P20 911401754042
PHILIPS BWS302 8LED 27K 24V A TM TB N10P20 911401754052
PHILIPS BWS302 8LED 27K 24V A DMX TB N10P20 911401754062
PHILIPS BWS302 8LED 27K 24V A DMX TM TB N10P20 911401754072
PHILIPS BWS302 8LED 30K 24V A LR N10P20 911401754082
PHILIPS BWS302 8LED 30K 24V A TM LR N10P20 911401754092
PHILIPS BWS302 8LED 30K 24V A DMX LR N10P20 911401754102
PHILIPS BWS302 8LED 30K 24V A DMX TM LR N10P20 911401754112
PHILIPS BWS302 8LED 30K 24V A TB N10P20 911401754122
PHILIPS BWS302 8LED 30K 24V A TM TB N10P20 911401754132
PHILIPS BWS302 8LED 30K 24V A DMX TB N10P20 911401754142
PHILIPS BWS302 8LED 30K 24V A DMX TM TB N10P20 911401754152
PHILIPS BWS302 8LED 40K 24V A LR N10P20 911401754162
PHILIPS BWS302 8LED 40K 24V A TM LR N10P20 911401754172
PHILIPS BWS302 8LED 40K 24V A DMX LR N10P20 911401754182
PHILIPS BWS302 8LED 40K 24V A DMX TM LR N10P20 911401754192
PHILIPS BWS302 8LED 40K 24V A TB N10P20 911401754202
PHILIPS BWS302 8LED 40K 24V A TM TB N10P20 911401754212
PHILIPS BWS302 8LED 40K 24V A DMX TB N10P20 911401754222
PHILIPS BWS302 8LED 40K 24V A DMX TM TB N10P20 911401754232
PHILIPS BWS302 9LED RGB 24V A DMX LR N10P20 911401754242
PHILIPS BWS302 9LED RGB 24V A DMX TM LR N10P20 911401754252
PHILIPS BWS302 9LED RGB 24V A DMX TB N10P20 911401754262
PHILIPS BWS302 9LED RGB 24V A DMX TM TB N10P20 911401754272
PHILIPS BWS302 9LED RGBNW 24V A DMX LR N10P20 911401754282
PHILIPS BWS302 9LED RGBNW 24V A DMX TM LR N10P20 911401754292
PHILIPS BWS302 9LED RGBNW 24V A DMX TB N10P20 911401754302
PHILIPS BWS302 9LED RGBNW 24V A DMX TM TB N10P20 911401754312
